Frap Tools333 Mixer + Distributor
Frap Tools 333
The Frap Tools 333 consists of three separate groups of three summing mixers. Each of the module’s inputs and outputs are DC coupled, meaning they are compatible with both CV and audio rate signals. Additionally, 333 features buffered outputs that make it an ideal means of distributing quantized CV while maintaining the integrity of the signal.
Additionally, the module contains a -6dB pad switch on each channel so that users can appropriately tame the volume of excessive input signals. Since the 333’s bottom and top sections are normalled together, the module can also operate as a 1:9 multiple.
- 3 x 3 mixers/distributors
- DC coupled, works with CV
- Buffered, works with quantized voltages
- 6dB attenuator switch
- 1 to 9 buffered mult
- Eurorack Module
- Width: 6HP
- Depth: 38mm
- Current Draw: 48mA@+12V, 48mA@-12V
