Twisted Electrons AY3-8912 Vintage Computer Synthesizer

Item#
N13-5597
8hp
In Stock Available immediately!
  • Free Shipping
  • No Hassle Returns
  • Extended Warranty
  • Low Price Guarantee
$229.00



Twisted Electrons AY3-8912

The Twisted Electrons AY3-8912 is the Eurorack incarnation of their AY3 MKII synthesizer. The module derives its sound from an AY3-8912 chip, which was used in many classic ‘80s video games. Like it’s older sibling, the module features two oscillators and an arpeggiator. However, because it is optimized for Eurorack, the AY3-8912 features CV control over all crucial parameters. All this and more makes the module a welcome addition to any Eurorack modular setup, especially those aspiring or appealing to various aspects of vintage 8-bit compositions.

AY3-8912 Features

  • AY-3-8912 chip
  • 2 square oscillators
  • Arpeggiator with 3 arp chords
  • Tuned noise osc
  • Dual function trigger, pitch and output
  • Noise gate pitch and output
  • Tune knob with 1 octave range
  • Spread knob for osc 1 and 2
  • Noise Pitch knob
  • Trigger inputs: 5V pulse
  • V/oct & Pitch Inputs: 0-5v DC Positive
  • Outputs: +/-5V (10v peak to peak)
  • Unit includes 16pin power cable and screws
  • 8HP
  • 2mm deep

5V external mode:

  • 5V: 74mA
  • 12V: 7mA
  • -12V: 7mA

5V internal mode:

  • 12V: 80mA
  • -12V: 7mA
