Prism SoundTitan USB Audio Interface

Item#
N13-04787
$4,724.00

Special Order Reserve yours today!

Special Order

We don't usually stock this item but will place an order with the manufacturer as soon as you check out. Shipping times vary, so please contact us for more information.
  • Free Shipping
    Free
    Shipping
  • Warranty
    Extended
    Warranty
  • Low Price Guarantee'
    Low Prices
    Guaranteed
Special order delivery times vary. Note that special orders may not be returned or cancelled. Feel free to reach out for more info!

Prism Sound Titan

Brilliance and clarity come naturally to Prism Sound's Titan, an 18-channel audio interface supporting loads of analog and digital options coupled with pristine clocking and dynamics. The front panel sports a fantastic metering solution with view and control over sync, input selection, leveling, per-channel overkill limiting, and a wonderful master volume knob that acts as a push encoder for navigating your Titan's user interface. Additionally, you have immediate access to the first two audio channels in the form of instrument preamps via TS 1/4" jacks, as well as two independent TRS 1/4" headphone outputs with individual level control.

On the rear of Titan, you will find an array of I/O and connectivity to fit a variety of audio operations. These include four combo XLR/TRS 1/4" inputs that can act as preamps for microphones or line level sources, with a fantastic dynamic range of 116dB, a total harmonic distortion of -117dB, and switchable input sensitivity of either +4dBu or -10dBV. This versatility is great for recording any number of instruments or sources at the perfect level with low noise. On top of having an additional four line level inputs, both the mic and instrument preamps have an abundance of gain, reaching up to 65dB over 1dB increments. You also have eight analog outputs for monitoring, creating send and return setups, or whatever your output needs desire with a dynamic range of 115dB and total harmonic distortion of -107dB.

Titan records and produces transparent and sample-accurate audio over digital means by supporting up to eight channels over ADAT as well as 2 channels over S/PDIF, thanks to the RCA and TOSLINK ports. Access the hidden AES3 operation via the included RCA-XLR adaptor, or even sync your gear or your Titan over Wordclock via the BNC connection. Connecting to your Mac or PC's DAW is easy and fast over the USB type-B connection, and further expansion with a Pro Tools HD or Dante system can be adjusted with the supplementary Prism Sound cards available for purchase.

For even more control over your Titan's routing, gain staging, and connectivity, Prism Sound provides a Titan Controller applet that makes setting up and customizing your Titan a cinch. The available and proprietary Verifile software component even furthers the stability by checking for clicks, errors and drop outs without any compromise, making it to where you get the perfect recording and streaming experience. For a pristine and malleable recording and monitoring experience, add the wonderful interfacing solution that is Titan to your audio rig.

Titan Features

  • 18-channel USB audio interface
  • Eight simultaneous analog inputs and outputs, including support for mic, line, and instrument levels
  • Flexible digital inputs and outputs with support for ADAT, S/PDIF, Wordclock, and even AES3 via XLR-to-RCA conversion
  • Impeccable digital clocking with finesse over jitter rejection
  • Ultra-low latency feeds via the flexible, built-in digital mixer
  • USB type B connection to Mac or PC, and expansion ports for supporting Dante or Pro Tools HDX
  • Titan Controller applet gives you further depth and control over metering, sample-rate selection, overload and overkill, as well as DAW routing
  • Includes Verifile technology to help find and prevent errors in your recordings and live-streams
  • Analog Inputs:
    • 4x combo XLR/TRS 1/4" supporting mic and line level
    • 2x TS 1/4" instrument level
    • 4x TRS 1/4" line level
  • Analog Outputs: 8x TRS 1/4" line level
  • Headphone Outputs: 2x 1/4" TRS
  • Digital Inputs:
    • 1x BNC Wordclock
    • 1x ADAT optical
    • 1x S/PDIF or AES3 RCA
  • Digital Outputs:
    • 1x BNC Wordclock
    • 1x ADAT optical
    • 1x S/PDIF or AES3 RCA
  • USB: Type-B
  • Sample Rate: up to 192kHz
  • OS Requirements:
    • Mac: OS X 10.4+, Intel platform
    • Windows: Vista, 7 or 8 (32 or 64 bit)
  • Physical Specifications:
    • Form: 1U 19inch rack mountable
    • Dimensions: 440mm x 290mm x 50mm
  • Power: 90-250VAC, 50/60Hz via IEC 6A connector
  • Power Consumption: 35W
