Dual Discrete VCA

Koma Elektronik Dual Discrete VCA

The Koma Elektronik Dual Discrete VCA is a high-quality amplifier for audio signals with many user-friendly features. Each VCA channel features two AC-coupled inputs with adjustable pre-gain. The gain stages provide useful attenuation at lower settings before swaddling the input with tasty saturation as gain is increased. Two CV inputs, linear/exponential slope control, and bias/offset knobs optimize each channel for use with all manner of modulation sources. When left unpatched, the output of Channel A is mixed with the output of Channel B, allowing the Dual Discrete VCA to be used effectively as a colorful mixer as well.

Dual Discrete VCA Features

• Analog dual-channel VCA
• Two audio inputs per channel with adjustable gain for each
• Linear/Exponential response knobs per channel
• Bias A+B controls
• Two CV inputs (one attenuated) for each channel
• Output A normalled to putput B
