CIOKSDC5 Link Power Supply

No Longer Available Contact us for a recommendation.


DC5 is a compact professional power supply with 5 isolated outlets. Since it is a mere 31mm high, it can fit under most Pedaltrain boards. It provides 9, 12, or 18v, with a max output current of 900mA. The top two outputs are switchable between 9 and 12v, the middle is 18v, and the bottom two are also 9 or 12v.

DC5 Features

  • 5 isolated outlets with 9, 12 or 18V
  • total output current of 900mA
  • two powerful outlets, 300mA each
  • one outlet configurable to 18V
  • high efficiency toroidal transformer
  • short circuit protection of all outlets
  • advanced LED monitoring of each outlet
  • 120 or 230V mains voltage operation
  • detachable mains power cord
  • with CIOKS unique mains link feature, DC5 easily adds 5 extra isolated outlets to another link power supply
  • 10 Flex cables included
  • Split Flex included
  • super flat design, fits under Pedaltrain PT-nano or PT-mini
  • mounts easily to pedal boards
  • Outlet 1-2: 9 or 12V DC / 100mA each
  • Outlet 3: 9 or 18V DC / 100mA
  • Outlet 4-5: 9 or 12V DC / 300mA each
  • Size: 130x88x31mm (excl. detachable rubber feet)
  • Weight: 0,7kg
  • Warranty period: 5 years worldwide
