TINRSEdgecutter Visual Envelope

TINRS Edgecutter

TINRS’ Edgecutter is an intuitive envelope generator that provides immediate visual indication of its current state. It features a line of LEDs that let the user know precisely where the envelope is at. This handy feature gives users an extra edge when patching, creating even more space for creative modulations.

Edgecutter Features

• Gate input for easy start/stop behavior
• Retrig initiates the envelope cycle while the gate input is open
• Velocity input for scaling the peak of the envelope
• Trigger button for manual start/stop
• Dedicated knobs and CV inputs for each envelope stage
• Three modes of operation
• One-shot mode: pulse traverses entire envelope with sustain as intermediate point
• Gate mode: Gate opens to move envelope through attack and decay
• Repeat: changes sustain to repeating A/D cycle
• Speed button alternates between fast and slow envelopes
• Curvature parameter alternates between exponential and logarithmic slopes
• Dual envelope outputs, one with integrated curvature settings
